WD G-Technology G-RAID with Thunderbolt 3
High-Performance, Dual-Drive Storage
G-RAID Removable Thunderbolt 3 USB-C - 8TB
#0G05748
- Capacity: 8TB
- Transfer Rate: Up to 500MB/s
- Color: Silver
- Drive Speed: 7200 RPM
G-RAID Removable Thunderbolt 3 USB-C - 12TB
#0G05753
- Capacity: 12TB
- Transfer Rate: Up to 500MB/s
- Color: Silver
- Drive Speed: 7200 RPM
G-RAID Removable Thunderbolt 3 USB-C - 16TB
#0G05758
- Capacity: 16TB
- Transfer Rate: Up to 500MB/s
- Color: Silver
- Drive Speed: 7200 RPM
G-RAID Removable Thunderbolt 3 USB-C - 20TB
#0G05763
- Capacity: 20TB
- Transfer Rate: Up to 500MB/s
- Color: Silver
- Drive Speed: 7200 RPM
G-RAID Removable Thunderbolt 3 USB-C - 24TB
#0G05768
- Capacity: 24TB
- Transfer Rate: Up to 500MB/s
- Color: Silver
- Drive Speed: 7200 RPM
G-RAID Removable Thunderbolt 3 - 28TB - Silver
#0G10414
- Capacity: 28TB
- Transfer Rate: Up to 500MB/s
- Color: Silver
- Drive Speed: 7200 RPM
Overview:
The G-RAID with Thunderbolt 3 is an ultra-fast, dual 7200RPM Enterprise-class hard drive storage system featuring multiple RAID options for ultimate flexibility and reliability.
The G-RAID with Thunderbolt 3 is a high-performance, dual Enterprise-class 7200RPM hard drive storage system featuring Thunderbolt 3, USB–C (supports USB 3.1 Gen 2) and HDMI connectivity for ultimate flexibility. With removable drives, this ultra-fast, high-capacity storage solution is designed for the most demanding applications while easily supporting multi-stream HD, 2K, 4K and HDR video workflows.
Key Feature
- Dual Thunderbolt 3 ports and a single USB-C port with support for USB 3.1 Gen 2
- Daisy chaining for up to 5 additional devices
- Dual removable, Enterprise-class 7200RPM hard drives
- High-speed data transfers
- Hardware RAID 0 (performance), RAID 1 (mirroring), or JBOD
- HDMI port supports HDR and 4K video pass through
- 5-Year limited warranty
Features:
Stylish, Aluminum Design
A storage device provides sturdy desktop storage in a stackable, silver aluminum case designed to neatly complement your workspace.
RAID Storage with Thunderbolt 3
Up to 24TB1 of Enterprise-class 7200 RPM hard drive storage give you long-term sustained performance and enhanced reliability for all your demanding workloads.
High-Speed Transfer Rates
With transfer rates up to 500MB/s, the G-RAID with Thunderbolt 3 device delivers the performance you need to quickly ingest content and natively edit footage to make changes in real-time.
Built-In Hardware RAID
the G-RAID with Thunderbolt 3 device comes configurable in RAID 0, RAID 1, or JBOD to provide a versatile and flexible storage solution.
Removable, Enterprise-Class Storage
For all your demanding workloads and mission-critical footage, you can depend on the power and enhanced reliability of two (2) removable Enterprise-class 7200RPM hard drives inside.
Thunderbolt 3, USB-C and HMDI Ports
Dual Thunderbolt 3 ports and a single USB-C port with support for USB 3.1 Gen 2 and HDMI port supports HDR and 4K video pass through.
Daisy-chaining for up to 5 additional devices
Dual Thunderbolt 3 ports allow you to daisy chain up to five additional devices through a single connection to your computer, so you can stay connected to multiple drives, 4K displays and more.
5-Year Limited Warranty
G-RAID with Thunderbolt 3 is backed by a standard 5-Year limited warranty and unlimited free technical support by representatives experienced with the latest content creation applications.
1 As used for storage capacity, one terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment.
2 Based on read speed. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per second. Performance will vary depending on your hardware and software components and configurations
Specifications:
| G-RAID with Thunderbolt 3 Specifications | |
|---|---|
| Interface | (2) Thunderbolt 3 ports (1) USB-C (USB 3.1 Gen 2) port (1) HDMI (HDCP 2.2 supports 4K 60/HDR) |
| Drive | (2) 7200 RPM Enterprise-class hard drive |
| Data Transfer Rate | 8TB: Up to 360MB/s 12TB: Up to 440MB/s 16TB: Up to 400MB/s 20TB: Up to 480MB/s 24TB: Up to 500MB/s |
| Size (LxWxH) | 9.92" x 5.12" x 3.58"/ 252 x 130 x 91 mm |
| Weight | 6.58 lbs |
| System Requirements | macOS 10.12+ Windows 10, 8.1 (via reformat) |
| Box Contents | G-RAID with Thunderbolt 3 dual-drive storage system (1) Thunderbolt cable (20 Gbps) (1) USB-C to USB-A cable for backward compatibility (compatible with USB 3.1 Gen 2, 3.0 and 2.0) AC power adapter Power cable Quick Start Guide 5-Year limited warranty |
| Retail Packaging (LxWxH) | 8.90” x 11.93” x 6.81” |
Compare:
| Product | Thunderbolt | USB-C | USB | FireWire | eSATA | mini-SAS | RAID Enabled | ev Series | Enterprise-class1 HDD |
|---|---|---|---|---|---|---|---|---|---|
| G-SPEED Shuttle with Thunderbolt 3 | |||||||||
| G-SPEED Shuttle XL with Thunderbolt 3 | |||||||||
| G-SPEED Shuttle XL with Thunderbolt | |||||||||
| G-SPEED Shuttle with ev Series Bay Adapters (Thunderbolt 3) | |||||||||
| G-SPEED Shuttle XL with ev Series Bay Adapters (Thunderbolt 3) | |||||||||
| G-SPEED Shuttle XL with ev Series Bay Adapters | |||||||||
| G-RAID with Thunderbolt 3 | |||||||||
| G-RAID with Thunderbolt | |||||||||
| G-RAID with Removable Drives | |||||||||
| G-RAID USB with Removable Drives | |||||||||
| G-DRIVE with Thunderbolt 3 | |||||||||
| G-DRIVE USB-C | |||||||||
| G-DRIVE with Thunderbolt | |||||||||
| G-DRIVE USB |
1 Used in extreme “enterprise” environments such as multiuser computer systems, server applications, and tiered storage arrays.
Views:
Video:
Documentation:
Download the WD G-Technology G-RAID with Thunderbolt 3 Datasheet (.PDF)
